PDQ15-Q24-S5-D
Manufacturer:
Same Sky
Mfr.Part #:
PDQ15-Q24-S5-D
Datasheet:
Description:
DC to DC Converters DIP-6 Through Hole Nominal Input Voltage:9 V to 36 V Min Input Voltage:9 V Max Input Voltage:36 V 87 %
| Parameter | Value |
|---|---|
| Length | 25.4 mm |
| Width | 25.4 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Height | 10.2 mm |
| Packaging | Bulk |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Features | OCP, OVP, SCP, UVLO |
| Min Input Voltage | 9 V |
| Output Current | 3 A |
| Output Voltage | 5 V |
| Max Power Dissipation | 15 W |
| Max Output Current | 3 A |
| Max Input Voltage | 36 V |
| Number of Outputs | 1 |
| Isolation Voltage | 1 kV |
| Output Power | 15 W |
| Efficiency | 87 % |
| Voltage - Output 1 | 5 V |
| Nominal Input Voltage | 9 V to 36 V |
| Output Current-Channel 1 | 3 A |
| Output Voltage-Channel 1 | 5 V |
Stock: 66
Distributors
pcbx
pcbxUnit Price$26.95337
Ext.Price$26.95337
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $26.95337 | $26.95337 |
| 10 | $25.95789 | $259.57890 |
| 25 | $24.99917 | $624.97925 |
| 50 | $24.07586 | $1203.79300 |
| 100 | $23.18654 | $2318.65400 |
